LED Street Light with innovative & aesthetic & robust design with aluminium heat sink and toughened glass (IP66)
| Octa Pole | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Pole Type | Length | Section | Thick | Top | Bottom | Base Plate | Arm | Bolt | PCD |
| Octa Pole | 5M | 1 | 3mm | 70mm | 130mm | 220x220x12 | 1000mm | M16 | 220 |
| Octa Pole | 6M | 1 | 3mm | 70mm | 130mm | 220x220x12 | 1000mm | M16 | 220 |
| Octa Pole | 7M | 1 | 3mm | 75mm | 130mm | 220x220x12 | 1000mm | M20 | 220 |
| Octa Pole | 8M | 1 | 3mm | 70mm | 130mm | 220x220x12 | 1000mm | M20 | 225 |
| Octa Pole | 9M | 1 | 3mm | 70mm | 130mm | 220x220x12 | 1000mm | M20 | 260 |
| High Mast | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Pole Type | Length | Section | Thick | Top | Bottom | Base Plate | Arm | Bolt | PCD |
| High Mast | 12M | 2 | 3mm | 130mm | 320mm | 530X20 | Ring 4 | M24 | 440 |
| High Mast | 16M | 2 | 3,3mm | 150mm | 360mm | 560X20 | Ring 6 | M24 | 460 |
| High Mast | 20M | 2 | 3,4mm | 150mm | 410mm | 610X20 | Ring 8 | M28 | 510 |
| Octa Pole | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Pole Type | Length | Section | Thick | Top | Bottom | Base Plate | Arm | Bolt | PCD |
| High Mast | 25M | 3 | 4,4,3mm | 150mm | 475mm | 675X25 | Ring 10 | M30 | 575 |
| High Mast | 30M | 3 | 5,4,3mm | 150mm | 530mm | 750X30 | Ring 12 | M30 | 650 |
